ARI 3-590 Collaborative Robotic Arm
The ARI 3-590 is engineered for high-precision welding and cutting in demanding industrial environments. Designed for consistent output and reliable operation, it enhances productivity while maintaining tight quality control across fabrication workflows.
ARI 3-590 Specifications
| Parameter | Details |
|---|---|
| Collaborative Model | ARI 3-590 |
| Reach | 590mm ( 23 inches) |
| Max Payload | 3 kg (6.61 lbs) |
| Weight (Net / Gross) | 13 kg / 20 kg (28.66 lbs / 44.09 lbs) |
| Repeatability | ±0.02 mm |
| Power Supply | 220–240 VAC, 47–63 Hz, 10A 100–200 VAC, 47–63 Hz, 16A |
| Axes | 6 |
| Teach Pendant | Included |
| Electrical Control Box | Included |
| Warranty | 2 Years |
