ARI 12A/1.46 Industrial Robotic Arm
The ARI 12A/1.46 is built for precision and efficiency in industrial robotic automation. It delivers stable, repeatable results across welding and cutting applications while supporting optimized production workflows.
ARI 12A / 1.46 Specifications
| Parameter | Details |
|---|---|
| Industrial Model | ARI 12A / 1.46 |
| Reach | 1465 mm (51.18 inches) |
| Max Payload | 12 kg (26.4555 lbs) |
| Weight (Net / Gross) | 130 kg (286.6 lbs) |
| Repeatability | ±0.03 mm |
| Motors | 400W SV-X2MG0402-B2KA-XS45 |
| Axes | 6 |
| IP Class | IP54 / IP65 |
| Communication | TCP/IP, Modbus/TCP, Profinet, Ethernet/IP |
| Warranty | 2 Years |
