ARI 500P Pulsed Laser System
The ARI 500P is a pulsed laser system designed for high-precision applications including fine welding, marking, and cleaning. It provides controlled energy delivery for delicate and detail-oriented fabrication processes.
ARI 500P Laser Cleaning Machine
| Parameter | Details |
|---|---|
| Product Model | ARI 500P |
| Laser Power | 500 W |
| Control System | Custom Cleaning System |
| Optical Fiber Interface | QBH |
| Cooling System | Water Cooling System |
| Lens Reflection Wavelength | 1050–1090 nm |
| Rated Power | ≤ 500 W |
| Scanning Width | 120 mm |
| Cleaning Efficiency | 0.08–8 ㎡/min |
| Scanning Speed | < 30000 mm/s |
| Auxiliary Air Pressure | ≥ 0.5–0.8 MPa |
| Cleaning Mode | Straight / Rectangle / Ellipse / Wave / petalspiral / Grid / 8 |
| Working Voltage | 380V 3ph 50Hz/60Hz |
| Operating Temperature | -15°C to +65°C |
| Field Lens | F300 (Optional: F254/F300) Transformer Included |
| Warranty | 2 Years |
SPARES
| Component | Details |
|---|---|
| Collimating Lens | -- |
| Reflecting Lens | -- |
| Field Lens | -- |
| Protective Lens | D43*2 |
| Protective Lens 1 (Air Knife) | -- |
| Protective Lens 2 (Field Lens) | -- |
| Air Knife Nozzle | -- |
